intelligent 2.2 W 12V 5050 24 Key IR led strip lights rgb remote controller with 3 CMOS manufacturer from China KEYS ELECTRONIC CO., LTD

intelligent 2.2 W 12V 5050 24 Key IR led strip lights rgb remote controller with 3 CMOS

Place of Origin:

Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

intelligent 2.2 W 12V 5050 24 Key IR led strip l

intelligent 2.2 W 12V 5050 24 Key IR led strip lights rgb remote controller with 3 CMOS

DC5V, 12V, 24V led controller with remote
Connect RGB strip:30M
Used with RGB led strips&modules
24 Key IR control
CE, ROHS

Packaging & Delivery
Packaging Detail : Normal white box packing:1pc/box
1.Supply Voltage: DC5V, 12V , 18V, 24V optional(specify the required voltage on orders)
2.output power: 30W(5V), 72W(12V), 144W(24V
3.output: 3 CMOS open-drain output
4.connection mode: common anode, Common cathode
5.Display Mode: 24 Key IR control, 20 modes speed adjustable brightness adjustable
6.Working Temperature -20-60°C
7.Connect RGB strip:30M

Applications:
LED intelligent contrioller is dedicated to adjust the brightness of LED lights, which adopted the most advanced PWM (Pulse-Width Modulation) digital brightness-adjusting technology at present, users can either operate manually or use the IR wireless remote controller to control the brightness in the distance, they are suitable for commercial and household 86-style socket installation, the socket can be installed outside or inside the wall. LED intelligent dimmer can meet different brightness requirements at different time, and can extend life tenure of LED, suitable for adjusting the brightness of both low-power and hi-power LED illumination lights, energy-saving.

Specifications:

Model	LT-RF1606 Wireless dream color strip controller (1606) Wireless magic digital strip controller (1606
Work temperature	-20-60
Supply voltage	DC12V
Size	945826mm
Gross weight	240g
Power rating	2.2 W
Output:	two groups SPI signal
Function	it has 84 grayscale, Length setup funtion and Power-fail memory function, you could choose it freely in a lot of programs
